4G PV Stick Logger with Meter Monitoring
4G LTE Cat 1 bis Connectivity
RS485 & RS232 Meter Communication
Automatic Network Reconnection & Data Synchronization
Real-Time Inverter & Meter Data Acquisition
Secure SSL/TLS Data Communication
Remote Configuration, Diagnostics & Reboot
Single Phase Solar GTI — INV(EU)-EGT-01 Series (1.5kW–6kW)
Patented Cooling Design
Advanced thermal design for stable operation
Wide AC Grid Voltage Range
Supports grid voltage up to 290V
24H Replacement Support
365-day uptime support
Unique H6 Topology
Prevents leakage current
AFCI (Optional)
Advanced safety option
IP65 Protection
Dust & water resistant
INV(EU)-EGT-01 Series
INV(EU)-E-1.5 GT-01 INV(EU)-E-3.3 GT-01 INV(EU)-E-5 GT-01 INV(EU)-E-2.0 GT-01 INV(EU)-E-3.6 GT-01 INV(EU)-E-6 GT-01 INV(EU)-E-2.2 GT-01 INV(EU)-E-4.0 GT-01 INV(EU)-E-3.0 GT-01 INV(EU)-E-4.2 GT-01
Communication Device
- Residential grid-tied inverter range spanning 1.5kW to 6kW capacities (10 models)
- Graphic LCD display with WiFi standard and RS485 optional communication
- Max PV input voltage of 550V with start-up voltage of 65–70V
- Nominal PV input voltage of 450V, MPPT voltage range of 100–500V
- Single independent MPPT input with max operating current up to 22A (30A DC short-circuit)
- Nominal AC output power from 1500W to 6000W, max apparent power up to 6600VA
- Nominal AC voltage of 220/230V with wide voltage range of 140–300V
- IP65 degree of protection per IEC 60529, smart cooling method
- Achieves up to 97.8% max efficiency and 99.90% MPPT efficiency
- THD below 1.5% at rated power, adjustable power factor of ±0.8
- Full protection suite: grid monitoring, DC reverse polarity, short-circuit, leakage current, surge, and anti-islanding protection
- Recommended max PV input power from 2250Wp to 7800Wp, depending on model
- Compliant with CE, EN/IEC 61000, IEC 62109, BIS, IEC 60068-2, and VDE-AR-N 4105 standards
- Transformerless topology with wall-mounting bracket design
- MC4-compatible DC connectors, plug-and-play AC connection
- Operating ambient temperature range of -25°C to 60°C, humidity tolerance of 0–95%
- Compact dimensions (315x300x108mm for smaller units), weighing 5–8kg
- Grid frequency support of 50Hz/45–55Hz, 60Hz/55–65Hz
- Best suited for residential rooftops and small home solar installations.
Residential Rooftops
- Ideal for small to medium-sized homes
Shops & Offices
- Reduce electricity costs efficiently
Farmhouses & Villas
- Reliable and clean solar power
Net-Metering Systems
- DISCOM compliant integration
CERTIFIED SAFETY
- IEC 62109-1 / 2 compliant
- International safety standards
GRID READY
- IEC 61727 certified
- Reliable grid connectivity
BIS CERTIFIED
- India compliance approved
- Built for local standards
CE & EMC COMPLIANT
- Electromagnetic compatibility
- Reliable and stable operation
Technical Highlights
(Refer to datasheet for detailed specifications.)
